Description
The Keysight (Agilent) E4982A LCR Meter provides the best performance for the passive component manufacturing such as SMD inductors and EMI filters, where impedance testing at high frequencies (1 MHz to 3 GHz) is required. Not only for the manufacturing, the E4982A can also be utilized for R&D, quality assurance with the powerful functions such as list measurements.
Features of the Keysight (Agilent) E4982A LCR Meter:
- Frequency: 20 Hz to 2 MHz, with 4-digit resolution in any range
- Basic accuracy: 0.05% basic accuracy with superior measurement repeat-ability at low and high impedance
- Built-in 40V DC Bias (Option 001)
- 40 A DC support with the option 002 and the 42841A Bias Current Source
- Rdc measurements (Option 200)
- 20 Vrms test signal (Option 001)
- High-speed measurements: 5.6 ms
- 201 points list sweep
- Versatile PC connectivity (LAN, USB and GPIB)
Measurement Characteristics of the Keysight (Agilent) E4982A LCR Meter:
- Measurement Parameters:
- Impedance parameters |Z|, |Y|, Ls, Lp, Cs, Cp, Rs, Rp, X, G, B, D, Q, Øz [°], Øz [rad], Øy [°], Øy [rad], User defined parameter (A maximum of four parameters can be displayed at one time.)
- Measurement Range:
- Impedance parameters 140 mΩ to 4.8 kΩ (Frequency = 1 MHz, Averaging factor = 8, Measurement time mode = 3, Oscillator level = 1 dBm, Measurement uncertainty ≤ ± 10%, Calibration is performed within 23 °C ± 5 °C, Measurement is performed within ± 5 °C from the calibration temperature)
Contact TestWorld today for the best price on the Keysight (Agilent) E4982A LCR Meter, 1 MHz to 3 GHz.
Explore Financial options to find a cost management solution best for your company:
Configurable Options for the Keysight (Agilent) E4982A LCR Meter:
E4982A-004 |
Add Working Standard Set
|
US$ | 599 |
E4982A-019 | Standard hard disk drive | US$ | 0 |
E4982A-020 |
Add Test Fixture Extension Cable Set
|
US$ | 1,056 |
E4982A-1A7 | Calibration + Uncertainties + Guardbanding | US$ | 393 |
E4982A-1CM | Rackmount kit | US$ | 62 |
E4982A-1CN | Front handle kit | US$ | 111 |
E4982A-1CP | Handle/rack mount kit | US$ | 122 |
E4982A-700 | US$ | 1,627 | |
E4982A-710 | Test Fixture Stand | US$ | 354 |
E4982A-720 | 3.5mm to 7mm Coaxial Adapter | US$ | 354 |
E4982A-810 | Add keyboard | US$ | 122 |
E4982A-820 | Add mouse | US$ | 73 |
E4982A-A6J | ANSI Z540-1-1994 Calibration | US$ | 393 |
