Description

Teledyne LeCroy LABMASTER-10-36Zi 36 GHz, 80 GS/s, 4ch, 20 Mpts/Ch LabMaster Slave Acquisition Module, 50 Ohm Input

The Teledyne LeCroy LABMASTER-10-36Zi oscilloscope is a graph-displaying device – it draws a graph of an electrical signal. In most applications, the graph shows how signals change over time: the vertical (Y) axis represents voltage and the horizontal (X) axis represents time. The intensity or brightness of the display is sometimes called the Z axis.

The Teledyne LeCroy LABMASTER-10-36Zi oscilloscope’s simple graph can tell you many things about a signal, such as: the time and voltage values of a signal, the frequency of an oscillating signal, the “moving parts” of a circuit represented by the signal, the frequency with which a particular portion of the signal is occurring relative to, other portions, whether or not a malfunctioning component is distorting the signal, how much of a signal is direct current (DC) or alternating current (AC) and how much of the signal is noise and whether the noise is changing with time.

Teledyne LeCroy – LABMASTER 10-36ZI Specifications

• Up to 65 GHz
• Up to 80 Channels @ 36 GHz
• Up to 160 GS/s
• Up to 1024 Mpts/Ch
• Ultra-low jitter noise floor (100 fs rms) and ultra-high time base stability
• 5.2 ps (20-80%) rise time
• 14.1 Gb/s hardware serial trigger (28 Gb/s in development)

• 60 GHz maximum real-time bandwidth
• 4 Channels all at silicon-based 36 GHz bandwidth
• Upgradeable in bandwidth
• 5.5 ps rise time
• 160 GS/s sample rate at 60 GHz
• 1024 Mpts/Ch maximum analysis memory
• LabMaster architecture permits up to:

20 channels at 36 GHz

10 channels at 60 GHz

• ChannelSync™ provides precise synchronization of all channels for high time/phase accuracy (<200 fs rms)
• 30 GHz trigger bandwidth
• 100 fsrmsjitter noise floor
• Acquisition front-end and track/hold based on low-noise 8HP Silicon-Germanium (SiGe)
