Description

Teledyne LeCroy – OE-525 wide-band multi-mode optical to-electrical converters are designed for measuring optical communications signals. Their broad wavelength range and multimode input optics make these devices ideal for applications including Gigabit Ethernet and Fibrechannel, as well as SONET/SDH up to 2.5 Gb/s. The OE525 is a ProLink modules compatible with WaveMaster, SDA and DDA instruments.

Teledyne LeCroy – OE-525 Specifications

• Frequency range to 5 GHz (6 GHz optical)
• 62.5 um multi-mode fiber input
• 500 nm to 870 nm Wavelength
• Responsivity: 1.1 V/mW
• Noise: 1.1 uW rms

• Frequency range to 5 GHz(6 GHz optical)
• 62.5 μm multi-mode fiber input
• Broad wavelength range:500–870 nm (OE425) and (OE525) 950–1630 nm (OE455) and (OE555)

• High responsivity:1.1V/mW
• Low noise:1.1 μW rms
