Description

Spirent – EDM-2003B Features & Specifications:

The Series 1000 modules support up to 16,384 streams per port. These attributes make the Series 1000 test modules a cost effective solution for production test environments or in research and development environments where high scalability performance testing is not required.

The Series 2000 Gigabit Ethernet test modules suit customers with total flexibility including conformance test capabilities, Layer 2/Layer 3 scalability with basic routing, through advanced Layer 3 with high performance routing capabilities. Additionally, the Series 2000 GigE modules measure performance of IPTV, Layer 4 to 7 devices such as firewalls, load balancers, IDS/IPS systems, SSL accelerators, Web accelerators and SSL and IPSec VPNs.

Series 2000 modules can scale up to 32,767 streams per port. When combined with highscale Spirent TestCenter software components, they offer the complete high performance testing solution.

In addition to the Gigabit Ethernet test modules, Spirent also offers Series 1000 and Series 2000 10-Gigabit Ethernet modules, creating a full spectrum of Ethernet test modules from 10Mbps to 10GbE.

10/100/1000 Dual Media Module for TestCenter. 12-ports per module. The dual media interface has both copper and fiber interfaces on a single module. 10/100/1000 Mbps and 1Gigabit Ethernet port densities range from 2 ports up to 96 ports in a single chassis.

Spirent – EDM-2003B Specifications

• Wire-rate and beyond wire-rate traffic generation and analysis at Layers 2 and 3
• Supports up to 32,767 transmit streams per port and up to 65,535 receive streams per port
• Supports RFC 2889 LAN switching performance and RFC 2544 L2/L3 performance tests
• Modules can be hot-swapped
• Unified automation features shared by all Spirent TestCenter components

Spirent – EDM-2003B TECHNICAL SPECIFICATIONS

Analyzer – HyperFilters „

• Five different traffic analysis filters may be placed anywhere in the packet for the user to select packet fields for measurement and statistical tracking analyses
•  The analyzer supports a combination of 5 filters, 4 16-bit and 1 32-bit that operate on the incoming traffic stream „
• Separates traffic into as many as 65,535 sub-streams for detailed analysis „
• Automatically identifies Layer 2 (including MPLS and VLANs), Layer 3 and Layer 4 encapsulations per templates

Spirent – EDM-2003B KEY FEATURES

„ High port density modules with per-port group reservation, providing multi-user capability

„ Dual media test modules provide 10/100/1000 Mbps and Gigabit Ethernet fiber „

Wire-rate and beyond wire-rate traffic generation and analysis at Layers 2 and 3 „

Compatible with all Spirent TestCenter software applications for comprehensive functional, conformance and performance testing in one system

„ Supports all core technologies required to test Enterprise L2/L3 switches, including QoS, IPv4/v6, multicast, routing, spanning tree, multiple spanning tree, VLAN and DHCP. Simultaneously runs multiple protocols per port to emulate large routed networks. „

Series 2000 GigE modules support testing of application level protocols such as HTTP, SSL, FTP, Telnet, DNS, IPv6, IPSec, Capture/Replay for L4-7, SIP, SMTP and POP3

Spirent – EDM-2003B APPLICATIONS „

• Use Series 1000 modules combined with the SPT-5000A or SPT-9000A chassis to achieve high volume production testing where high-density, low cost Ethernet ports are required
• „ Benchmark network device scalability and limitations at a cost effective price
• „ Develop and test your device in the lab with the Series 1000 or Series 2000 test modules, then carry them to your customer site installed in an SPT-2000A portable chassis to prove your device’s performance.
• „ Compare and validate network equipment to determine the suitability of a specific application prior to deployment
• Ensure the performance of advanced network devices. Such features encompass total host/ client capacities and throughput, QoS class prioritization, SLA bandwidth verification, VLAN tagging and dozens of routing protocols, scalability protocols and performance metrics.
