Description
Spirent – CPR-1001B Features & Specifications:
The Series 1000 modules support up to 16,384 streams per port. These attributes make the Series 1000 test modules a cost effective solution for production test environments or in research and development environments where high scalability performance testing is not required.
In addition to the Gigabit Ethernet test modules, Spirent also offers Series 1000 and Series 2000 10-Gigabit Ethernet modules, creating a full spectrum of Ethernet test modules from 10Mbps to 10GbE
1000 SERIES – 10/100/1000 COPPER RJ-45, 8 PORT. Requires small form factorcardcarrier if used in 2U/9U.
Spirent – CPR-1001B Specifications
- Wire-rate and beyond wire-rate traffic generation and analysis at Layers 2 and 3
- Supports up to 32,767 transmit streams per port and up to 65,535 receive streams per port
- Supports RFC 2889 LAN switching performance and RFC 2544 L2/L3 performance tests
- Modules can be hot-swapped
- Unified automation features shared by all Spirent TestCenter components
Spirent – CPR-1001B KEY FEATURES
- High port density modules with per-port group reservation, providing multi-user capability
- Dual media test modules provide 10/100/1000 Mbps and Gigabit
- Ethernet fiber
- Wire-rate and beyond wire-rate traffic generation and analysis at Layers 2 and 3
- Compatible with all Spirent TestCenter software applications for comprehensive functional testing and performance analysis all in one system
- Supports automated industry standard RFC 2889 LAN switching performance and RFC 2544 L2/L3 performance tests
- Supports all core technologies required to test Enterprise L2/L3 switches, including QoS, IPv4/v6, multicast, routing, spanning tree, VLAN, and DHCP. Simultaneously runs multiple protocols per port to emulate large routed networks
- Series 2000 GigE modules support testing of application level protocols such as HTTP, SSL, FTP, Telnet, DNS, IPv6, IPSec, Capture/Replay, SIP, SMTP and POP3
-
Custom packet and frame editing is facilitated by a graphically driven field editor that allows the user to edit templates for a wide variety of preconfigured control and data plane packets
-
Real-time per stream statistics, such as minimum, maximum, and average latency per traffic class
-
Real-time event log allows user to view actual protocol messaging on a per-port basis
-
Hardware is field-programmable. The module can be upgraded on site in its chassis as new features and technologies become available
Spirent – CPR-1001B TECHNICAL SPECIFICATIONS
Transmit Generator Specifications
- Up to 32,767 unique streams on a port
- Set packet rate per stream
- Edit up to 6 variable fields per stream
- Test duration: continuous, time burst, frame burst
- Load units: frames/second or % of line rate
- Burst size in frames
- Loads: fixed, stepped, or random with minimum and maximum
- Frame sizes: fixed, stepped, or random with minimum and maximum
Spirent – CPR-1001B BENEFITS
Reduce lab space and test equipment costs:
High port density modules that support multi-user operation provide
maximum efficiency on utilization of hardware resources
Protect your investment for future projects:
Dual media test modules provide both copper and fiber Ethernet interfaces (10/100/1000 Mbps and Gigabit fiber)
Ease of service:
All Spirent TestCenter modules are hot swappable for easy
service or replacement while the chassis is fully operational. They can easily be managed remotely through an IP network. The Spirent TestCenter Administration Application provides a single software tool to manage your entire investment in Spirent TestCenter components.
Leverage test equipment purchases:
Use the same hardware platform to perform research and development using the interactive capabilities for pinpointing potential issues, performing comprehensive functional testing and high scale performance testing.
Spirent – CPR-1001B APPLICATIONS
Spirent TestCenter customers use Series 1000 modules combined with the SPT-5000A or SPT-9000A chassis to achieve high volume production testing where high-density, low cost Ethernet ports are required.
Users can test devices from various manufacturers to benchmark their scalability and limitations at a cost-effective price. Develop and test your device in the lab with the Series 1000 or Series 2000 Test modules, then carry them to your customer site installed in an SPT-2000A portable chassis to prove your device’s performance.
Compare and validate network equipment to determine the suitability of a specific application prior to deployment. The modules help to compare and validate equipment for compliance to product specifications prior to deployment, and ensure that advanced features such as host client capacities, QoS class prioritization, VLAN tagging, routing protocol scalability/performance, security protocols and IP Multicast will perform as
expected. Customers can also use the test modules to verify routing control and converged network capabilities.
