Description
The HP Keysight – Agilent E9326A, 50 MHz to 18 GHz Peak and Average Power Sensor has a 1.5 MHz bandwidth, and is used with the EPM-P series power meters and E9288A-C sensor cables. The E9326A features fast measurement speed (up to 1000 corrected readings per second via the GPIB), wide dynamic range, calibration factors, linearity, temperature and bandwidth correction stored in EEPROM, and a precision type-N connector as standard.
The E9wer m326A diode power sensor has a 1.5 MHz video bandwidth and is ideal for time-gated peak, average and peak-to-average ratio poeasurements on TDMA and CDMA wireless formats such as Bluetooth.
1xEV-DO wireless systems — simplify development, verification, and manufacturing with the EPM-P power meters and E9320 E-Series power sensors.
Key Features & Specifications E9326A:
- 1.5 MHz video bandwidth, ideal for Bluetooth® and cdmaOne applications
- Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
- Wide dynamic range
- Calibration factors, linearity, temperature and bandwidth correction stored in EEPROM
- Precision type-N connector as standard
- Operates with the EPM-P (E4416A/ 17A) series and P-Series (N1911A/ 12A) power meters
