Description
The 80333A from Giga-tronics is a Power Sensor with Frequency 10 MHz to 26.5 GHz, Max Input Power +33 dBm (2 W). More details for 80333A can be seen below.Giga-tronics 80333A True RMS Power Sensor, +20 to -30 dBm; 10 MHz to 26.5 GHz, K(m) Measure CW power from 10 MHz to 50 GHz at more than 17,500 readings per second over GPIB. Measure up to 90 dB with a single sensor, and select from a variety of high power sensors up to 50 W. These sensor groups work with the 8540B, 8540C, 8650A, 8650B and 58542 VXI series power meters and the 8003 Scalar Network Analyzer. Modulation-Power 80333A specifications: Description: 10 MHz to 18 GHz Characteristics: -30 dBm to +20 dBm Max Switched Current: +33 dBm (2 W) Max Switched Voltage: -30 to +20 dBm: ±0.00 dB Max Switched Power: Type K(m) 50 onm Bandwitch: 6.0 in. (152mm) Insertion Loss: 1.25 in. (32mm) Crosstalk: 0.6 lb (0.27kg) VSWR: 1.12: 0.01-12GHz/ 1.15: 12-18GHz / 1.18: 18-28.5GHz Standard Accessories included
Gigatronics 80333A Specifications:
- Part Number- 80333A
- Manufacturer- Giga-tronics
- Description- True RMS CW Power Measurement
- Power Measurement- RMS Power, CW Power
- Connector -K Type, K Type – Male
- Impedance -50 Ohms
- Frequency -10 MHz to 26.5 GHz
- VSWR-1.12: 0.01-12GHz/ 1.15: 12-18GHz / 1.18: 18-28.5GHz
- Max Input Power-+33 dBm (2 W)
