Gigatronics 80304A CW Power Sensor, 10 MHz to 40 GHz, +23 dBm (200 mW) Max Power

Shop > Products > Test Equipment > RF & Microwave Test Equipment > RF Power Sensors > Average (CW) Power Sensors > Gigatronics 80304A CW Power Sensor, 10 MHz to 40 GHz, +23 dBm (200 mW) Max Power
Gigatronics 80304A CW Power Sensor, 10 MHz to 40 GHz, +23 dBm (200 mW) Max Power
Gigatronics 80304A CW Power Sensor, 10 MHz to 40 GHz, +23 dBm (200 mW) Max Power

Gigatronics 80304A CW Power Sensor, 10 MHz to 40 GHz, +23 dBm (200 mW) Max Power

Categories: ,

Description

The Gigatronics 80304A is a CW Power Sensor with a frequency range of 10 MHz to 40 GHz and a power range of -70 dBm to + 23 dBm. VSWR of the Gigatronics 80304A Power Sensor is 1.12: 0.01 to 2GHz, 1.22: 2 to 12.4GHz, 1.29: 12.4 to 18GHz, 1.43: 18 to 26.5 GHz and 1.92: 26.5 to 40 GHz. It is compatible with the 8540x series and 8650A series of Power Meters

Gigatronics 80304A Specifications:

  • CW Power Sensor
  • Frequency Range:  10 MHz to 40 GHz
  • VSWR:
    • 1.12: 0.01 to 2GHz,
    • 1.22: 2 to 12.4GHz,
    • 1.29: 12.4 to 18GHz,
    • 1.43: 18 to 26.5 GHz and
      • 1.92: 26.5 to 40 GHz
