Description

The Anritsu S820C Hand-Held Microwave Analyzer for Antennas, Transmission Lines and Microwave Components, very sensitive receiver. It works on the principle of “super-heterodyne receiver” to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the Anritsu S820C.

Microwave Site Master S810C and S820C utilizes vector error correction solving the most common and the most difficult accuracy problems of field test equipment operation and thus, improves system quality and reduces maintenance expenses. Difficult test specifications are easy to verify. Vector error correction and a simple, friendly user interface within the S810C and S820C further improves the quality and convenience of measurements compared to traditional scalar techniques. Vector error correction also improves the quality of Distance-To-Fault data. Not only is the reflection magnitude more accurate, the waveguide dispersion correction for fault distance (different frequencies travel at different speeds) is also more accurate and repeatable.

Key Features Anritsu S820C:

• Handheld, battery-operated design
• Lightweight at only 4.2 lbs. (including battery)
• Superior Immunity to RF interference
• Locate long range problems with 517 data points
• Tune Mode for waveguide component alignment/testing
• Multilingual user interface; English, Portuguese, French, Chinese, Japanese, Spanish, German
• Saves 10 Measurement Test Set-Ups
• Saves up to 200 Measurement Traces
• Clearly defined user interface for Coaxial cable and Waveguide media
• Pop-up menus for cable list, waveguide list, and compatible flange list
• Quickly select cable/waveguide type and test parameters without setup error
• Alphanumeric Labeling of Saved Measurements
• Automatic Time and Date Stamp of Saved Data
• Rechargeable, Field Replaceable Battery
• Distance Measurement in Feet and Meters
• 6 Markers, Limit Lines, and Segmented Limit Lines
• RF Power Monitor Option (option 5)
• RS232 Interface
