Description

The Anritsu ML2487B Wideband Power Meter for Measuring 3G/4G, WLAN and WiMAX Signal Formats provides accurate peak power measurement for communications, wireless, and aerospace applications. For the design and implementation of wireless networks, they address the important issues of power control, peak power, and timing.

The performance of the signal channel and the range of product features make accurate and precise testing of the power envelope of communication and radar systems easy and straightforward. The ML2487B supports single sensor input, and the ML2488B supports dual sensors inputs.

With their high sampling rate of 64 Ms/s, these meters offer accurate peak power detection for wide bandwidth systems such as those compatible with 802.11a/b/g, eliminating the need for manual correction factors found on the current generation of power meters. The ML2488B dual channel sensor input and display allow simultaneous monitoring of WLAN and Bluetooth® wireless technology enabled devices, providing crucial testing for the co-existence of the multi-standards.

Key Features Anritsu ML2487B:

• Frequency Range 100 kHz to 65 GHz
• Rise Time <18 ns
• Accurate power measurements related to all Bluetooth and IEEE 802.11 WLAN, WiMAX, and TD-SCDMA
• High Speed GPIB and Ethernet remote control
• Peak, Average, and Crest Measurements
• Built in Statistics, CCDF, CDF and PDF
• Free! PC application
