Description

ASA M1 Waveform Viewer provides an easy-to-use, fast, simple and low cost way to capture, view, analyze, save and report on both saved and live waveforms from hundreds of scopes, digitizers, and SPICE waveform simulations.  Capture waveforms from any scope, digitizer, or EDA/SPICE tool then explore, share, analyze, and document the waveform wherever you prefer using the 22 built-in measurements/statistics, FFT, and Eye diagram. Or, instead of sending just a static screen shot, instantly send a fully explorable waveform to remote colleagues for assistance, review, or immediate decision closure using the Send Waveform button. If they don’t have M1 WV, they can click a link in the email and instantly download it.

ASA M1 Waveform Viewer Features:

• Waveform Capture:
  • Keysight (Agilent/HP) Oscilloscopes
  • LeCroy
  • Yokogawa
  • Rhode & Schwarz
  • Tektronix Oscilloscopes
  • From Agilent/Acqiris, National Instruments, and GaGe digitizers
  • From SPICE waveform simulations
  • Using both voltage vs. time waveforms and logic channel waveforms
  • Using single-shot upload, single acquisition, or acquisition sequences
  • From one device this morning and a different device this afternoon, etc.
• Analyze and Explore Waveforms
  • Waveform Comparison – Compare waveforms from different sources or different acquisition times on the same screen
  • Automatically make 17 common oscilloscope pulse-parameter measurements
  • Multi-acquisition analysis – Explore your waveforms in-depth
  • Multi-acquisition statistics for all 17 pulse parameter measurements
  • Measure behaviors using Markers for each view (2 pairs – horizontal and vertical)
  • Lock X-axes – Lock axes so that Scope and Logic views pan and zoom in step
  • ScopeTrack – understand where a Zoom view is in relation to the larger acquisition

ASA M1 Waveform Viewer lets you instantly collaborate via email, as well as inexpensively capture, view, analyze, save, and report on waveforms taken from any oscilloscope or digitizer in your lab, or from EDA simulation tools!

Benefits of the ASA M1 Waveform Viewer:

• There are many scope and digitizer brands and models. You probably have many of them in your lab. It’s hard to know what device you’re going to be using for any given task.
• You use SPICE waveform simulation to help you understand your parts as well.
• With WaveformViewer you don’t need to be concerned about using multiple tools.
• We’ve done all the work in bringing together disparate waveform data formats.
• Hundreds of devices and EDA Waveform Simulation tools… ‘One user interface ‘One way of computing the measurement
• You’re not tied down to the lab anymore
• Work with the measurements when it suits you; rather than when it fits into the device’s or EDA tool’s availability
• You probably have a better chair up in your office’ or at the coffee shop
• Everyone on the team can perform waveform exploration and analysis away from the source of the waveform
• Ease congestion around your most popular waveform acquisition devices and EDA tools
• Move M1 WaveformViewer around to capture and view waveforms from any source

Contact TestWorld today for more pricing and information on the ASA M1 Waveform Viewer.
